High Pressure Ball Valves API 6A

Home » Products » High Pressure Ball Valves API 6A

Engineered for you

High-Pressure Ball Valves ensure robust performance and safety under extreme pressure, meeting API 6A standards. With forged construction and flexible seat options, they’re ideal for upstream oil & gas operations.

Certified & Tested

PJ Valves high-pressure ball valves are certified and tested to meet the most demanding industry standards. Each valve is Designed & performance-tested in accordance with API 6A, fire-tested and certified to API 6FA, and verified for fugitive emissions per ISO 15848-1, Class BH. With SIL 3, ATEX, and CE PED approvals, these valves ensure maximum safety, reliability, and compliance for critical applications.

Product Range

We manufacture high-pressure trunnion mounted ball valves in full compliance with API 6A standards, while meeting API 6A requirements and specific customer specifications. Each valve is engineered for extreme pressure and temperature conditions, ensuring robust performance, safety, and reliability. Designed for critical applications, these valves incorporate advanced sealing technology, fire-safe features, and fugitive emission compliance to guarantee integrity in the most demanding environments.

  • Size Range -1/2" to 12"
  • Pressure rating- API 5000 PSI to API 10000 PSI
  • Temperature Ratings - API 6A K, L, P, R, S, T, U, V
  • Bore - Full or Reduced
  • Operation - Manual or Actuated
  • Construction - 2 or 3 Piece Body Design Side Entry, Forged

Material Scope

We specialize in meeting stringent material specifications, including NORSOK, and accommodating diverse end-user requirements for both metallic and non-metallic components. With increasingly severe upstream operating conditions, specifications now extend beyond primary valve components to include bolting and operator materials. Through established partnerships with our supply chain, PJ Valves ensures full compliance with any project specification, delivering reliability and integrity in every solution.

Body material

  • Carbon Steel
  • Duplex / Super Duplex Stainless Steel
  • Alloy Steel
  • Nickel Alloys

Trim material

  • Duplex / Super Duplex Stainless Steel
  • Alloy Steel with Hard Coating (ENP, Chrome, Tungsten Carbide)
  • Nickel Alloys

Seat Materials

  • Soft – PEEK
  • Metal- CRC, TCC, Stellite HVOF Coatings & Nickel fuse coatings

Features

Design Standard: API6A

PJ Valves API 6A high-pressure ball valves are engineered for extreme upstream oil & gas applications, providing reliable, gas-tight shutoff in the harshest operating conditions. Their forged, trunnion-mounted construction ensures strength and stability under high pressures, while advanced soft or metal-seated sealing systems deliver consistent performance. Fully compliant with API 6A, the valves incorporate fire-safe design, anti-blowout stem, and anti-static protection.

Features

  • PSL1 to PSL 3G, PSL 4 compliant
  • Emergency Sealant injections
  • Tight Shut off
  • Double body seal
  • Anti-blowout Stem
  • Locking arrangement
  • Anti-Static Device
  • Easy to actuate with ISO 5211 mounting pad
  • Bidirectional valve

Options

  • PR2 Tests
  • PR2F Tests
  • Stem extension
  • Compact Flanges
  • Hub ends
  • Weld Overlays Wetted area or Seal area
